| Model Number : | - 723861 2420mAh 3.7V |
| Certification : | IEC62133,UN38.3,CE,ROHS,UL,REACH |
| Payment Terms : | T/T,L/C |
Slim Form Factor: Thin 7.2mm profile ideal for space-constrained designs.
High Energy Density: Excellent capacity-to-weight ratio (2420mAh at only 45g).
Flexible Pouch Design: Can be customized for specific space requirements.
Low Internal Resistance: Enables high current delivery with minimal voltage drop.
Fast Charging Capability: Supports up to 1C (2420mA) charging current.
Safety Features: Built-in protection against overcurrent and short circuit.
Specification
| Rated Capacity | 2420mAh | |
| Nominal Voltage | 3.7V | |
| Charging Voltage | 4.2±0.03V | |
| Standard charge | Constant Current 0.5C 1210mA Constant Voltage 4.2V 0.01 C5A cut-off | |
| Standard discharge | Constant current 0.2 C 484mA end voltage 3.0 V | |
| Fast charge | Constant Current 1C 2420mA Constant Voltage 4.2V 0.01 C 24.2mA cut-off | |
| Fast discharge | Constant current 1C 2420mA end voltage 3.0 V | |
| Maximum Continuous Charge Current | 1 C 2420mA | |
| Maximum Discharge Current | 30C 72600mA | |
| Operation Teerature Range | Charge: 0~45℃ Discharge: -20~60℃ | |
| Storage Teerature Range | Less than 1 year: -20~25℃ less than 3 months: -20~40℃ | |
| Weight | 45g | |
| Dimension | 7.2mm(T)*38mm(w)61mm(h) | |

application
Portable Power Tools: Compact cordless tools needing high current output.
RC Vehicles: High-speed remote control cars, boats, and aircraft.
Portable Medical Devices: Compact medical equipment requiring high power density.
High-end Consumer Electronics: Ultra-thin gadgets and portable devices.
Robotics: Small robotic applications requiring high power output.
Emergency Power Systems: Backup power for critical applications.
Charging
Never exceed 4.2V charging voltage under any circumstances
Charge in fire-proof containers or bags only
Monitor temperature during charging - disconnect if above 45°C
Maintain ventilation during charging
Discharging
Monitor temperature during high-rate discharge
Allow cooling between high-current cycles
Never short-circuit terminals
Use appropriate wiring for high-current applications (≥16AWG recommended)
Storage & Handling
Store in cool, dry environment away from direct sunlight
Use protective casing to prevent physical damage
Keep away from sharp objects and metals
Store in fire-proof containers when not in use
|
